Supa-Trac X-Press
Supa-Trac X-Press is the ultimate lightweight pedestrian matting system. Sharing the traditional Supa-Trac design, it conforms to almost all ground types and conditions, yet it is thinner and has a lighter panel weight. At only 3.3 pounds per panel, this portable lightweight matting product is easy to handle and requires no tools for installation making it among the fastest mat on the market to install and remove.
Product Features
- Patented interlocking design
- Extreme strength to weight ratio of 36,000 lbs/sqft
- Manually deployable panels weighing only 3.3 lbs/panel
- Edging ramps are available for the elimination of trip hazards and ADA compliant access.
- World-class top surface design for traction.
Benefits
- Quick installation and extraction (manually deployable)
- No special tools or training needed to install
- Deployed in pre-assembled sections
- Product can be stored indoors or outdoors for years of flexible use
- Cost-effective solution for pedestrian, structure, and event applications
- Ideal for artificial turf, soil, sand or gravel, and all hard-standing surfaces
Dimensions
| Panel size (inches) | 39 (L) x 11.3 (W) x 1.1 (H) |
| Area Per Panel (sq ft/pc) | 2.3 |
| Weight Per Panel (lbs) | 3.3 |
| Static Compression Capacity (lbs/sq ft): | 36,000 (Solid sub-surface. Capacity varies depending on sub-surface) |
| Shipping (sq ft): | Trailer 53’: 27,600 |
| Flatbed 48’: 27,600 |
| Panel Size (mm) | 990 (L) x 287 (W) x 28 (H) |
| Area Per Panel (sq m/pc) | 0.21 |
| Weight Per Panel (kg) | 1.5 |
| Static Compression Capacity (kg/sq m) | 175,000 (Solid sub-surface. Capacity varies depending on sub-surface) |
| Shipping (sq m) | Trailer 16 m: 2,560 |
| Flatbed 15 m: 2,560 |
Download the specification sheet
Supa-Trac X-Press Specsheet pdf 1611 KBFor more information on this product and to request a product specification contact the IPL team below.
